wizard skrev:
Forskjellen på INT202 og INT203 er at 203 er bidireksjonal og altså støtter AES/EBU eller S/PDIF til Firewire, noe i hvert fall jeg ikke har bruk for.
Features of the INT202:
Two Firewire 400 sockets. Firewire 800 can be connected via an appropriate cable
Can be powered from the Firewire bus or from an optional power supply
Two XLR output sockets
Two RCA output sockets
Operates up to 192kHz sampling rate
Single wire operation at sampling rates of 44.1, 48, 88.2, 96 kHz
Single or dual wire operation at sampling rates of 176.4 or 192 kHz
Infrared remote control (optional) for volume and absolute phase
Volume control is dithered to avoid quantization distortion
Bit transparency check feature for testing the computer player software
Driver Software:
Supports Windows XP, Vista, Windows 7
Supports OSX 10.5 and higher
Applications:
Interfacing any D/A Converter to a computer for high quality soundfile playback.
Interfacing any digital audio equipment with a AES/EBU or S/PDIF input to a computer.
High quality volume control and absolute phase control of audio played back from a computer.
Size (approx.): depth: 11cm x width: 11cm x height: 5cm
Features of the INT203:
Two Firewire 400 sockets. Firewire 800 can be connected via an appropriate cable
Can be powered from the Firewire bus or from an optional power supply
One XLR output socket, one XLR input socket
One RCA output socket, one RCA input socket
Operates up to 192kHz sampling rate
Infrared remote control (optional) for volume and absolute phase
Volume control is dithered to avoid quantization distortion
Bit transparency check feature for testing the computer player software
Driver Software:
Supports Windows XP, Vista, Windows 7
Supports OSX 10.5 and higher
Applications:
Interfacing any D/A Converter or A/D Converter to a computer for high quality soundfile playback and recording.
Interfacing any digital audio equipment with a AES/EBU or S/PDIF input /
output to a computer.
High quality volume control and absolute phase control of audio played back from a computer.
Size (approx.): depth: 11cm x width: 11cm x height: 5cm
